BRILIX pump body flange bolt FXP, Albixon, SS, Combo Master
Dimensions and technical details
| Screw length including head | 32mm |
|---|---|
| Material | AISI 316 stainless steel |
| Thread | M6 |
This fastener secures the corresponding component of the pump assembly. Length, thread and head design must match the original screw.
Part code: 1ND01-01-022
Dimensions and technical details
| Screw length including head | 32mm |
|---|---|
| Material | AISI 316 stainless steel |
| Thread | M6 |
BRILIX pump body flange bolt FXP, Albixon, SS, Combo Master
This fastener secures the corresponding component of the pump assembly. Length, thread and head design must match the original screw.
Pool technician’s advice
Compare the length including the head, thread and material of the original screw. Do not confuse it with other motor fasteners.
What to check before ordering
The fastener holds the relevant assembly components in position. A damaged thread or head, or a missing fastener, can prevent correct assembly. Check the mating thread or nut as well.
Compatibility and part identification
| Shop code | 1ND01-01-022 |
|---|---|
| Models | FXP 150, 250, 370, 550, 750 |
| Diagram position | 14 |
How to choose the correct version
Compare the original length, diameter, thread type and head shape. Lid, hydraulic-section and motor bolts are not automatically interchangeable. For a listed assembly, use its specific description.
When to replace the part
Replace a missing fastener or one with a damaged head or thread. Check any separately listed washer or seal at the same joint.
Important points when replacing the part
The new fastener must engage without force. Follow the pump manufacturer’s assembly and tightening instructions; extra force will not repair a damaged mating part. Have a technician dismantle motor assemblies.
Version details
Disconnect the pump from the power supply and drain the water before disassembly. Motor repairs, capacitor replacement and mechanical seal installation should be carried out by a qualified technician.
Using the exploded diagram
The listed position refers to the corresponding assembly diagram. The arrow helps locate the part; for some small components it marks only the fitting area. Compare the original part, its code and the specific pump version before ordering. You are ordering the item named in this listing, not the complete assembly in the diagram.
Related spare parts guides
Need help identifying the part
Email info@chemie-bazen.cz with photographs of the original part and the pump rating plate. Include measured dimensions and the fitting location to help identify the correct version.
Additional parameters
| Category: | FXP pump spare parts – 150, 250, 370, 550, 750 |
|---|---|
| Weight: | 0.01 kg |
| Part type: | Screws & nuts |
| Compatible series: | FXP, Combo |
| Product type: | Spare part |
| Brand: | Brilix |
