Pentair Rainbow 300-C off-line tablet chlorinator, 2.2 kg
Rainbow semi-automatic off-line chlorine dispenser for chlorine or multifunction tablets.
The dispenser adds chlorine to the pool gradually and holds up to 2.2 kg of tablets (11 pieces), allowing long operation without adding a new tablet twice a week.
For pools of 10–80 m³
Tubing connections require holes to be drilled in the pipe.
| Parameter | Value |
|---|---|
| Chlorinator height | 535 mm |
| Chlorinator width | 125 mm |
| Height of tubing outlet above the ground | 230 mm |
Pool Specialist Opinion - Review
- + Simple chlorine flow control
- + Easy installation and maintenance
- + Suitable for a variety of pool systems
- + Robust and durable material
- - Need to observe safety precautions when handling chlorine
"The Pentair Chlorinator is a reliable and effective solution for maintaining pool water purity and quality. The semi-automatic function and easy installation make this product an excellent choice for pool owners."
Team Poolservis
The Pentair chlorinator is ideal for those looking for a practical solution for maintaining clean pool water. Its ability to regulate the amount of chlorine and ease of installation make this device a reliable helper for any pool owner.
Chlorine Dispenser - Chlorinator Installation Instructions:
1) Install the dispenser last on the filtration branch (i.e., after the filtration, UV lamp, solar heater, heat pump...) Connection to the piping requires only drilling the pipe feeding the water to the filtration - in front of the vessel (which will serve as the inlet to the chlorinator) and at the outlet last.
2)Install the injection and intake of the doser on the filtration branch last (i.e. after the filtration, UV lamp, solar heating, heat pump...). Always suction first and injection half a meter further.
If you are placing the chlorinator below the pool level, you must install a closing valve behind and in front of the pool to prevent water from spilling when the lid is opened
.
| Parameter | Value |
|---|---|
| Chlorinator height | 535 mm |
| Chlorinator width | 125 mm |
| Supplied hose length (to be cut into sections) | 240 cm |
OPENING THE DISPENSER
Before opening the dispenser, let the water flow through the dispenser for 15 minutes. 6.2 Turn off the pump and set the control valve to the "OFF" position. Close the taps in the recirculation circuit to prevent water from flowing out of the pool. Wait approximately 1 minute and then unscrew the dispenser lid. 6.3 To do this, press the lock and unscrew the lid nut counterclockwise. Do not breathe the chlorine vapours released from the dispenser!!!
7. REFILLING TABLETS INTO THE DISPENSER
Check the level of tablets in the dispenser weekly. Refill the dispenser with new 200g tablets as required, following the procedure below. Remove any old, crumbled tablet residue. 6/6 - 7.1. Using the drain valve, drain 2/3 of the water from the dispenser and carefully insert the tablets. 7.2 Refill water up to 1 cm below the edge of the dispenser body. 8. CLOSING THE DISPENSER. 8.1. Fit the combined lid, O-ring seal and union nut onto the dispenser body. Tighten the lid clockwise by hand. 8.2 Adjust the control valve to the desired position. Open all taps and start the pump.
The amount of chlorine flow can be regulated or completely shut off by the control valve.
Additional parameters
| Category: | Chlorinators |
|---|---|
| Weight: | 4 kg |
| Brand: | Astralpool |
