Transparent strainer lid for Badu Magic 4, 6, 8, 11
Dimensions and technical details
| Diameter of transparent lid | 11,7 cm |
|---|
The lid closes the strainer housing while allowing access for basket cleaning and inspection. Correct sealing depends on both the lid and its gasket.
Part code: 2921616010
Dimensions and technical details
| Diameter of transparent lid | 11,7 cm |
|---|
Transparent strainer lid for Badu Magic 4, 6, 8, 11
The lid closes the strainer housing while allowing access for basket cleaning and inspection. Correct sealing depends on both the lid and its gasket.
Pool technician’s advice
Do not confuse the transparent lid with the retaining nut at position 160.2. If it leaks, check the lid seal at position 412.1 too.
What to check before ordering
The lid provides access to the pre-filter basket for cleaning. If water leaks or air enters, check the gasket and seating surface before ordering a replacement lid.
Compatibility and part identification
| Part code | 2921616010 |
|---|---|
| Compatibility | BADU Magic 4, 6, 8, 11 |
| Diagram position | 160.1 |
How to choose the correct version
Compare lid shape, diameter and locking method. Check the particular pre-filter version and its seating rim. The listing title and description define the supplied item; other diagram parts are not automatically included.
When to replace the part
Replace a cracked, warped or damaged lid. If it leaks, inspect the seal and sealing face before tightening further.
Important points when replacing the part
Switch the pump off, disconnect power and release pressure as instructed before opening. Clean mating surfaces and fit the gasket without pinching it. Check for leaks after restarting.
Version details
Disconnect the pump from the power supply and drain the water before disassembly. Motor repairs, capacitor replacement and mechanical seal installation should be carried out by a qualified technician.
Using the exploded diagram
The listed position refers to the corresponding assembly diagram. The arrow helps locate the part; for some small components it marks only the fitting area. Compare the original part, its code and the specific pump version before ordering. You are ordering the item named in this listing, not the complete assembly in the diagram.
Related spare parts guides
Need help identifying the part
Email info@chemie-bazen.cz with photographs of the original part and the pump rating plate. Include measured dimensions and the fitting location to help identify the correct version.
Additional parameters
| Category: | BADU Magic pump spare parts – 4, 6, 8, 11 |
|---|---|
| Weight: | 0.2 kg |
| Druh dílu: | Víko a díly víka |
| Kompatibilní řada: | BADU Magic |
| Product type: | Náhradní díl |
| Brand: | Badu |
